OUK-02-2

OUK-02-2 is an electrohydraulic table with backup mechanоhydraulic drive. It's unique solution for thoracic surgery.

A special table with a narrow table top panel makes it possible to perform operations in the thoracic and abdominal surgeries.

The table provides comfortable positioning of the patient and the surgeon has the greatest possible access to the operating field. The lifting bridge is mounted in the dorsal section and controlled by remote console, allowing smooth adjustment and optimal surgeon access for lung surgery.

Features:

• All open metal surfaces and additional accessories are made of stainless steel
• Table base and column are protected by stainless steel covers
• Molded protective cover of the adjustment mechanism
• Using seamless technology, molded removable mattresses made from integral polyurethane foam with an antistatic effect, and an innovative antimicrobial treatment (Ultra Fresh)
• Split, removable leg sections
• Longitudinal shift up to 300 mm
• Electric extensible supports to fix the table
• Multipurpose rails made of stainless steel on all table top sections
• Head section with two tilts
• Can be used with wide range of additional accessories

Adjustments:

• Table top height– electrohydraulic / mechanohydraulic
• Table top longitudinal tilts – electrohydraulic / mechanohydraulic
• Table top lateral tilts – electrohydraulic / mechanohydraulic
• Dorsal section tilts – electrohydraulic / mechanohydraulic
• Longitudinal shift – electrohydraulic
• Lifting bridge - electrohydraulic
• Return table top to zero position - electrohydraulic

• Leg and head section tilts – mechanical by gas spring

Used with the following KPP sets:

Recommendation:

• Min. table top height (without mattress), not more than670 mm
• Max. table top height (without mattress), not less than1120 mm
• Table top length2150 mm
• Table top length (without head and leg sections), not less than1150 mm
• Table top width450 mm
• Table top width (incl. side rails)500 mm
• Table base height, not more than230 mm
• Table base length, not more than 1150 mm
• Table base width, not more than525/385 mm
• Longitudinal tilt (Trendelenburg/reverse-Trendelenburg position), not less than -30º/+30º
• Dorsal section tilt (up/down), not less than+75º/-45°
• Head section tilt (up/down), not less than+30º/-45°
• Leg section tilt (up/down), not less than+30º/-90°
• Lateral tilt (right/left)+20º/-20º
• FLEX/REFLEX position225°/105°
• Longitudinal shift, not less than300 mm
• Lifting height of the lifting bridge, not less than120 mm
• Safe working load, not less than250 kg
• Safe working load (with functions limitation)350 kg
• Table weight (without sets of accessories), not more than280 kg
• Power network settings~ 230 V, 50 Hz
• Maximum table load350 kg
