KGM-4P

KGM-4P Gynecological chair

Multifunctional gynecological chair is recommended for perinatal, consultative, and diagnostic gynecological centers, family planning centers, maternity hospitals and departments.

It is intended for examinations, manipulations, small and large gynecological operations. Thanks to a folding chair panel and an attached leg section, this model can be used for operations requiring a spinal position.

Gynecological chair is adjusted by a foot and hand control, which is convenient both for the doctor’s work and patient positioning.

The modern design of the gynecological chair and various upholstery material colors will help to make the gynecological office aesthetically attractive.

Various leg support systems can be used: arm rests with foot rests, arm rests with Goepel leg holders.

Initial low seating position and the arm rest with foot rest that can be tilted backwards to facilitate patient positioning make the chair comfortable and safe to use for people with disabilities.

It can be used in chair or bed position. Enhanced functionality up to operating table level

Features:

  • Chair height, back and seat sections, armrests with foot rests are adjusted by 4 independent electric drives
  • Stepless adjustment of the back and seat section
  • Metal parts of the attachments are made of stainless steel
  • Two castors for easy moving
  • Bowl with holder (9L). The removable gynecological bowl can be freely moved along the rails and fixed in the required position. The bowl can be easily removed from the holder for cleaning and disinfection
  • The head cushion position is adjusted by the length of the strap and fixed with a clamp
  • Led lighting of the column
  • Built-in sockets for additional devices
Warranty 24 months.

Attention!

The information presented on the website has an advertising nature. For up-to-date information on product design and its technical characteristics, please contact our sales department!
*Actual colours may differ from their appearance on your display device or printed page.

  • Chair height (sections in horizontal position):
  • - Min position, not more than560 mm
  • - Max position, not less than900 mm
  • Chair panel length (converted into table), not less than1390 mm
  • Seat and back section width, not less than620 mm
  • Width of the chair on the rails, not more than680 mm
  • Angle between seat and back sections130°…180°
  • Panel longitudinal tilt +19°….-5°
  • Angle adjustment range in the vertical plane of arm rests with foot holders, not less than40°
  • Safe working load200 kg
  • Chair weight, not more than130 kg
  • Electric drives supply voltage24V
  • Volume of the stainless steel container9 L
